QSC AC-S6T Passive Loudspeaker - White

12 ΑΤΟΚΕΣ ΔΟΣΕΙΣ
3 YEAR WARRANTY
QSC AC-S6T Passive Loudspeaker - White
QSC AC-S6T Passive Loudspeaker - White
QSC AC-S6T Passive Loudspeaker - White
QSC AC-S6T Passive Loudspeaker - White
QSC AC-S6T Passive Loudspeaker - White
QSC AC-S6T Passive Loudspeaker - White
Code :
010265
210.80 €
Available for immediate dispatch
Available in store

Add to wishlist
Compare
Close
Έως 12 δόσεις των 17.57 € με 0% επιτόκιο με πιστωτική κάρτα
Κέρδισε 2% €πιστροφή πληρώνοντας με κάρτες Eurobank
3 δόσεις των 70.27 € με 0% επιτόκιο με την Klarna
4 δόσεις των 53.70 € με 0% επιτόκιο με την tbi bank
MANUAL

Description

QSC AC-S6T, 6.5-inch 2-way, 130° conical passive speaker with recommended amplification up to 32W/8Ω, 100V with 30, 15, 7.5, 3.8W transformer taps, frequency range of 60Hz – 20kHz, sensitivity of 86dB, and maximum SPL of 101dB continuous / 107dB peak.

It belongs to the AcousticCoverage Series and meets the needs for background sound by offering a 130-degree coverage angle, thereby reducing the number of loudspeakers required per space. The AC-S6T can be tuned via QSC Intrinsic Correction™ when used with the Q-SYS™ platform and CXD series amplifiers, providing a complete and integrated solution.

Specifications

  • LF transducer: 165mm (6.5-inch) Polypropylene woofer with 25mm (1-inch) voice coil
  • HF transducer: 25mm (1-inch) Aluminium dome tweeter with 25mm (1-inch) voice coil
  • Effective frequency range: 60 Hz–20 kHz
  • Rated noise power / voltage: 30 watts / 15.5 volts rms
  • Broad-band sensitivity: 86 dB SPL
  • Coverage angle (-6 dB): 130° conical (500 Hz–5 kHz)
  • Directivity factor (Q): 6
  • Directivity Index: 8 dB
  • Maximum continuous SPL: 101 dB
  • Maximum peak SPL: 107 dB
  • Rated impedance: 8 ohms
  • Recommended amplifier power: 60 watts into 8 ohms
  • Transformer taps 100V: 30, 15, 7.5, 3.8 watts 8 ohm bypass
  • Input connector type: Euroblock connector with parallel output
  • Enclosure material: UV treated, high impact ABS polymer
  • Grille material: Powder coated steel
  • Yoke material: Powder coated steel with brass inserts
  • Product Dimensions (HxWxD) inches: 11.9 x 8.5 x 7.8
  • Product Dimensions (HxWxD) mm: 303 ? 215 ? 197
  • Net Weight: 8.3 lb / 3.8 kg

Specifications

Category
Passive loudspeaker
Tweeter Size (Inches)
1
Power W Peak
30
Impedance (Ohm)
8
Loudspeaker usage
Professional
Frequency Response
60Hz - 20kHz
Sensitivity (dB)
86
Maximum SPL (dB)
107
Transformer (100V)
Yes
Power tappings @ 100V (W)
30 / 15 / 7.5 / 3.8
Enclosure material
ABS
Outputs
Euroblock connector with parallel output
IP Protection
IP44
Width (mm)
215
Height (mm)
303
Depth (mm)
197
Weight (kg)
3.8
Colour
White
EAN13
684284066831
MPN
AC-S6T-WH
