ADJ VIZI WASH Z37
090570
ADJ Vizi Wash Z37 is a professional moving head wash fixture with variable motorized zoom (10 ~ 60°) and 37 20W Quad (RGBW / 4-IN-1) LEDs.
2-YEAR WARRANTY
ADJ Vizi Wash Z37 is a professional moving head wash fixture with variable motorized zoom (10 ~ 60°) and 37 20W Quad (RGBW / 4-IN-1) LEDs. It features 11 zones of LED ring control, smooth 16bit dimming control from 0-100%, Locking Power In/Out to daisy chain power, both Locking 3-pin and 5-pin DMX In/Out and a built-in USB port for a convenient connection to update software if needed.
Specifications:
Source:
- 37 OSRAM RGBW QUAD-LEDs
- Max. 9710 Lumens (Zoom out, full on)
- 1250 Lux @5m at 60°
- 17609 Lux @5m at 10°
- Max. 9710 Lumens (Zoom out, full on)
- 1250 Lux @5m at 60°
- 17609 Lux @5m at 10°
Optics:
- Motorized Zoom: 10°-60° (field angle)
Control:
- 2 Operational Modes: Program Mode & DMX Control
- 9 DMX Channel Mode: 14, 15, 17, 18, 19, 38, 39, 72 or 73 Channels
- RDM compatible (Remote Device management)
- 16bit Electronic Dimming 0-100%
- 6 Dim Modes (Standard, Stage, TV, Architectural, Thetare, Stage 2)
- Adjustable Dimmer Delay Time: 0.1secs - 10 secs
- 4 Dim Curves (Square, Linear, Inverted Square, S-Curve)
- Display: Color display with 4-button function menu
- 11-Zone & 4 Ring-Control
- 16bit Pan 540°
- 16bit Tilt 270°
- Pan/Tilt Target Mode
- 3 Fan Modes : Auto/High/Silent
- 9 DMX Channel Mode: 14, 15, 17, 18, 19, 38, 39, 72 or 73 Channels
- RDM compatible (Remote Device management)
- 16bit Electronic Dimming 0-100%
- 6 Dim Modes (Standard, Stage, TV, Architectural, Thetare, Stage 2)
- Adjustable Dimmer Delay Time: 0.1secs - 10 secs
- 4 Dim Curves (Square, Linear, Inverted Square, S-Curve)
- Display: Color display with 4-button function menu
- 11-Zone & 4 Ring-Control
- 16bit Pan 540°
- 16bit Tilt 270°
- Pan/Tilt Target Mode
- 3 Fan Modes : Auto/High/Silent
Colors:
- RGBW Color Mixing
- 64 Color Presets
- Built-In Zone Chase Patterns
- 44 Color Temperature Presets 2700K - 7000K
- 64 Color Presets
- Built-In Zone Chase Patterns
- 44 Color Temperature Presets 2700K - 7000K
Construction:
- PVC molding
- Includes Quicklock Omega Brackets
- Includes Quicklock Omega Brackets
Electrical:
- Power voltage: AC100-240V, 50/60Hz (Multi-voltage)
- Power consumption: 525W
- Power consumption: 525W
Connections:
- 3-& 5pin Locking DMX In/Out connections
- Locking Power In/Out connection
- USB-Service Port for Firmware updates
- Locking Power In/Out connection
- USB-Service Port for Firmware updates
Dimensions & Weight:
- Dimension: 408.4 x 226 x 520.3mm
- Weight: 18 kg.
- Weight: 18 kg.
New
- MPN
- Vizi Wash Z37
