Instead of selecting amplifier power based on the needs of the largest zone, you now have the freedom to use total amplifier power in any application. This enables more flexibility during the initial design, or later on-site when making unplanned changes that take advantage of surplus power.
Configure any channel for low-impedance (4-8 Ω) or high-impedance (70/100V) applications without bridging or using jumpers. Improve performance and reliability. The Dual Feedback Loop system, inherited from the field-proven Bose PowerMatch amplifier line, allows for continuous monitoring and control of both the current and voltage delivered to each output load. This combination provides improved linearity and lower distortion while protecting loudspeakers.
- Power W RMS
- 100
- Impedance (Ohm)
- 4 / 8
- Transformer (100V)
- Yes
- Frequency Response
- 20Hz - 20kHz
- Inputs
- Analog x 4 balanced, Dante x 4 digital
- Width (mm)
- 483
- Height (mm)
- 44
- Depth (mm)
- 414
- Weight (kg)
- 6.4
- MPN
- PowerShare PS404D
